Compare Editions

Suitable for different application areas, the Diagnostician is available in three various editions.
To see the feature matrix please click here.

Basic Edition

Basic Edition includes the following functions:

Supported data sources
- Customer-specific interface to your maintenance software (on request)
- 'XML' (Universal data exchange format)
Vibration evaluation
- according to DIN ISO 10816-2 & 3
- with custom specific boundaries
Spike energy (BCU / Bandpass) evaluation
- with custom specific boundaries
- automatic volatile increase detection
Frequency spectrum diagnosis with
- autodetection of unbalance
- autodetection of misalignment
- residual range checkup
Envelope spectrum diagnosis with
- residual range checkup
Analysis module
- 'Overall' trend-diagram (new)
- 'BCU/Bandpass' trend-diagram (new)
- 'Frequency spectrum' diagram
- 'Envelope spectrum' diagram
- Standard cursor with Peak-Indicator (extended)
- Comment area
Diagnosis-Report
- Clear presentation of diagnostic results in tabular form
- Display of measurement configuration
- Display of overall values
- Frequency spectrum' diagram
- 'Envelope spectrum' diagram
- 'Adjustable plot height (new)
- Print-out

Availability:	Available in german and english
Price:	800 EUR
The standard license includes the diagnosis of up to 100 machines. If you run more than 100 machines, please ask for our volume licences.
All products are targeted at businesses and self-employed customers. Therefore all prices are listed without V.A.T.

See

Try

Buy

See

Try

Buy

Standard Edition

Standard Edition comprises all Basic Edition functionality.
Additionally it offers the following new functions:

Frequency spectrum diagnosis with
- autodetection of roller bearing problems
- autodeection of user-definable symptom-markers
- Exclusion areas¹
Envelope spectrum diagnosis with
- autodetection of roller bearing problems
- autodeection of user-definable symptom-markers
- Exclusion areas¹ (new)
Analysis module
- 'TrueHarmonic' Cursor (extended)
- Bearing-Symptom Cursor (extended)
- Cursor to display user-defined symptom-markers (new)
- Text-Cursor to display comments in diagrams (new)
Measurement-Report (new)
- Diagram presentation of all overalls and spectra of one point or machine
- Display of overall trend
- Display of corresponding frequency-spectrum
- Display of BCU/Bandpass trend
- Display of corresponding envelope-spectrum
- Adjustable plot height
- Print-out
Measurement-Overview
- Clear presentation of all overalls of one machine
- Display of overalls of a machine
- Display of overalls of a measurement point
- Adjustable plot height (new)
- Print-out
Bearing database
- Assign bearing data from broad bearing database
- Create user-defined bearing datasets
- Calculate new bearings based on their geometry

¹ Exclusion areas give you the possibility to exclude certain frequency ranges from diagnosis.

Availability:	Available in german and english
Price:	1.600 EUR
The standard license includes the diagnosis of up to 100 machines. If you run more than 100 machines, please ask for our volume licences.
All products are targeted at businesses and self-employed customers. Therefore all prices are listed without V.A.T.

See

Try

Buy

See

Try

Buy

Professional Edition

Professional Edition comprises all Standard Edition functionality.
Additionally it offers the following new functions:

Frequency spectrum diagnosis with
- user-definable symptom-markes with up to 10 sidebands
- user-definable symptom-markers with up to 10 harmonics
Envelope spectrum diagnosis with
- user-definable symptom-markes with up to 10 sidebands
- user-definable symptom-markers with up to 10 harmonics
Analysis module
- Peak-Indicator for frequency-spectrum diagram (new)
- Peak Indicator for envelope-spectrum diagram (new)
- Peak-List for frequency-spectrum diagram (new)
- Peak-List for envelope-spectrum diagram (new)
- Sideband-Cursor (new)
- Gearbox-Cursor (new)
Report-Assistant
- Smart data export to Microsoft Word (Version 2000,2003,2007,2010,2013 & 2016):
- Report-Template management
- Text-Module management
Additional diagnostic algorithms (on request)

Availability:	Available in german and english
Price:	2.400 EUR
The standard license includes the diagnosis of up to 100 machines. If you run more than 100 machines, please ask for our volume licences.
All products are targeted at businesses and self-employed customers. Therefore all prices are listed without V.A.T.

See

Try

Buy

See

Try

Buy

Feature Matrix

Basics	Basic	Standard	Professional
Language versions
german	•	•	•
english	•	•	•
Data source connections
Local	•	•	•
Network	•	•	•
Data source types
XML	•	•	•
Customer-specific interface to your maintenance software		on request	on request
Data source hierarchy
Easy-to-use tree view	•	•	•
Level - Filter	•	•	•
Result - Filter	•	•	•
Setup - Filter	•	•	•
Service functionality
'First Steps' introduction	•	•	•
WebUpdate - Onlinecheck for new versions	•	•	•
Feedback - Direct link to debids data's feedback formular	•	•	•
Remote service module	•	•	•
Sync Module for ...
Customer-specific interface to your maintenance software		on request	on request

Diagnosis	Basic	Standard	Professional
Diagnosis parameters
Save	•	•	•
Manage	•	•	•
Vibration evaluation
... according to DIN ISO 10816 partl 2 & part 3	•	•	•
... with custom specific boudaries	•	•	•
additional standards		on request	on request
Spike energy (BCU/Bandpass) evaluation
... with custom specific boundaries	•	•	•
... with automatic volatile increase detection	•	•	•
Frequency spectrum diagnosis
Residual range checkup	•	•	•
Autodetection of unbalance	•	•	•
Autodetection of misalignment	•	•	•
Exclusion areas		•	•
Autodetection of roller bearing problems		•	•
Autodetection of user-definable symptom-markers		•	•
- with up to 10 sidebands			•
- with up to 10 harmonics			•
Envelope spectrum diagnosis
Residual range checkup	•	•	•
Exclusion areas		•	•
Autodetection of roller bearing problems		•	•
Autodetection of user-definable symptom-markers		•	•
- with up to 10 sidebands			•
- with up to 10 harmonics			•

Analysis	Basic	Standard	Professional
Analysis module
Comment area	•	•	•
'Overall' trend-diagram	•	•	•
'BCU/Bandpass' trend-diagram	•	•	•
'Frequency spectrum' diagram	•	•	•
'Envelope Spectrum' diagram	•	•	•
Y-Axis normalization	•	•	•
Zoom	•	•	•
Standard Cursor with Peak-Indicator	•	•	•
'TrueHarmonic' Cursor		•	•
Bearing-Symptoms Cursor		•	•
Cursor to display user-definable symptom-markers		•	•
Text-Cursor to display comments in diagrams			•
Sideband-Cursor			•
Gearbox-Cursor			•
Peak-Indicator for frequency-spectrum diagram			•
Peak-Indicator for envelope-spectrum diagram			•
Peak-List for frequency-spectrum diagram			•
Peak-List for envelope-spectrum diagram			•

Reports	Basic	Standard	Professional
Diagnosis Report
Clear presentation of diagnostic results in tabular form	•	•	•
Display fo measurement configuration	•	•	•
Display of overalls and spectras	•	•	•
Adjustable plot size	•	•	•
Print-out	•	•	•
Measurement-Report
Diagram presentation of all overalls of one point or machine		•	•
Display of overall trend		•	•
Display of corresponding frequncy-spectrum		•	•
Display of BCU/Bandpass trend		•	•
Display of corresponding envelope-spectrum		•	•
Adjustable plot height		•	•
Print-out		•	•
Measurement-Overview
Clear presentation of all overalls of one machine		•	•
Display of overalls of a machine		•	•
Display of overalls of a measurement point		•	•
Display of overall history		•	•
Adjustable plot height		•	•
Print-out		•	•
Report-Assistant
Smart data export to Microsoft Word (Version 2000, 2003, 2007, 2010, 2013 or 2016)			•
- Hierarchy Names			•
- Diagnosis Report (complete)			•
- Diagnose Report (paragraph-based)			•
- Machine-Measurement Report (complete)			•
- Machine-Measurement Report (paragraph-based)			•
- Analysis Diagrams			•
Report-Template management			•
Text-Module management			•

Bearing database	Basic	Standard	Professional
Bearing-Assistant
Assign bearing data from broad bearing database		•	•
Create user-defined bearing datasets		•	•
Calculate new bearings based on their geometry		•	•
